ENGINE

EngineLH173M, Single cylinder, 4 stroke

Power19HP

Bore x Stroke72.5 × 66.8 mm

Compression Ratio9.5:1

Fuel SystemCARB

CoolingWater Cooled

Start TypeElectric

TransmissionAutomatic L-H-N-R

DriveRear Wheel Drive 2×4

​

SUSPENSION / BRAKES / TYRES

Suspension FrontMcPherson independent suspension

Suspension RearSwing arm

Brakes FrontDisk brake, Hand brake, Foot brake

Brakes RearDisk brake, Hand brake, Foot brake

Tyres FrontAT24×8-12

Tyres RearAT24×11-10

​

DIMENSIONS

​

Product Dimensions2100mm × 1140mm × 1270mm

Ground Clearance170 mm

Wheelbase1215 mm

Load Capacity129kg

Dry Weight310 kg

Fuel Capacity14 L

Max Speed>60 km/h

​

SAFETY

SafetyUsing ATV with Passenger greatly increases risk of Rollover. Speed should be kept under 15 km/h.

OPTIONS

Winch$399

​

The Crossfire X300 is a practical, value-focused 2WD farm ATV designed to handle general-use tasks across Australian rural properties. As an entry-level model in our range, it provides essential features with reduced daily maintenance requirements—ideal for riders who need capability and compliance without premium pricing.

It’s the first in our lineup to feature a sealed shaft drive and differential system, which eliminates the routine upkeep of traditional chain-driven systems. The automatic gearbox with high and low range, combined with a larger clutch and increased torque, makes the X300 well-suited for everyday farm duties like moving gear, light towing, or getting around uneven terrain.

A wider seat with additional padding improves comfort during longer rides, while the water-cooled engine and large radiator help maintain performance in Australia’s hotter and more rugged environments.

The X300 meets Stage Two of the Consumer Goods Quad Bike Safety Standard, including a Quad Bar Flexi CPD safety device fitted by your authorised dealer. It also exceeds the minimum lateral tilt stability angle of 28.81°, achieving a tested result of 32.4°.

While the X300 is not a high-end utility quad, it offers a well-rounded combination of functionality, safety, and value—making it a solid option for general-purpose use around farms and properties.

Speak with your nearest authorised Crossfire dealer to learn more or see the X300 in person.

WARRANTY

12 months up to 24 months*

* If 1 month and 6 months services have been done by a Crossfire Dealer – warranty is extended to 2 years for vehicles 250cc and up. Please make sure you have proof of services.

​

​
